Product Description
| Interface | 8* 1G/2.5G/5G/10G Base-T RJ45 RJ45 Port | System Management | Support Command Line Interface (CLI), Console port, Telnet, SSH and WEB configuration management Support Virtual Cable Testing (VCT) Support SNMP V1/V2c/V3 management Support SNTP protocol Support hierarchical user rights Support user RADIUS remote authentication Support user Tacacs+ remote authentication |
| Environment Temperature | Working Temperature: -10°C～50°C Storage Temperature: -40°C～70°C Working Humidity: 10%～90%, non-condensing Storage Humidity: 5%~90%, non-condensing |
Power Supply | DC 12V/1.5A |
| Dimension & Weight | 207*136*35mm (L*W*H） | Power Consumption | ≤36W |
Key Feature
8*10G SFP+ port
Backwards compatible with 1G/2.5G/10G transmission rate
10Gbps SFP+ optical module, Support s SR/LR/LRM/ER/ZR and other models
Layer3 static and dynamic routing protocol
Two aggregation modes, static aggregation and dynamic aggregation (LACP), effectively increase link bandwidth, improve link reliability, and can also achieve load balancing and link backup
Flexible and convenient management and maintenance, Support ing various management modes, such as Console, Telnet and SSH
WEB/CLI/ SNMP management
File upload and download management via TFTP
Purchase Info
| Model | Description |
| S5720-8X | 8* 1G/2.5G/5G/10G Base-T RJ45 RJ45 Port |
| External power adpater, 12 VDC/2A | |
| CN / EU / USA Plug Optional |
