Hardware Specification
|
Attributes |
Description |
|
Interface |
8*XG(S)-PON/GPON Combo port, 8* GE/10GE SFP + 2*100G QSFP28 |
|
Exchange Capacity |
720Gbps |
|
Forwarding Rate |
535.68Mpps |
|
Memory & Flash |
DRAM: 2GB; Flash: 8GB |
|
Management Port |
Console, MGMT |
|
PON |
Comply with ITU-T G.987/G.988 standard Wavelength: GPON: 1490nm downstream & 1310nm upstream; XSGPON: 1577nm downstream & 1270nm upstream; |
|
GPON: Downstream - 2.5Gbps, Upstream - 1.25Gbps; XGPON: Downstream - 10Gbps, Upstream - 2.5Gbps. XGSPON: Downstream - 10Gbps, Upstream - 10Gbps; |
|
|
GPON supports a maximum distance of 60KM logical distance 20KM physical distance, and 20KM differential distance; XGPON supports a maximum distance of 100KM logical distance 40KM physical distance, and 40KM differential distance; |
|
|
PON port 1:256 Maximum split ratio in total: GPON 1:128, XGPON/XGSPON 1:128 Standard OMCI management function; PON module adapts to standard 20PIN SFP+ package module |
|
|
Fan |
Modular fans supply * 3 |
|
Power |
AC: 100~240V 47/63Hz; DC: 36V~75V |
|
Power Consumption |
≤120W |
|
Weight |
6.5kg |
|
Dimensions (W *H *D) |
440mm*44mm*270mm (not including mounting ears) |
|
Environment Temperature |
Working Temperature: -10°C~55°C Storage Temperature: -40°C~70°C |
|
Environment Humidity |
Relative Humidity: 5%~95% (non-condensing) |
Key Feature
Ø Maximum split ratio of 1:128, connecting up to 1024 ONTs
Ø Rich Layer 2/3 switching features, flexible management methods
Ø Comply with ITU-T G.984/987/G.988 technical standards, with good connectivity capabilities
Ø Pon port supports GPON/XGPON/XGSPON three modes
Ø Support 128K MAC address
Ø Support FlexLink/STP/RSTP/MSTP/ERPS/LACP/ACL/QoS
Ø Support CLI, Telnet, WEB, SNMP V1/V2/V3, SSH2.0, OMCI protocol
Ø Support RIP、OSPF、BGP、ISIS and IPV6
Ø Support Power redundancy backup, Modular power supply, Modular fans supply
Ø Support ONT power failure alarm
Ø Support batch software upgrades on ONUs
Ø Flexibly compatible with any brand of ONTs
Purchase Info
|
Model Number |
Description |
|
GP5810-08 |
8*XG(S)-PON/GPON port, 8*GE/10GE SFP + 2*100G QSFP28 |
|
XGS-PON COMBO SFPP transceiver-GPON Class C+-XGS-PON Class N2 |
|
|
AC/DC optional dual power supply |
|
|
EU & US power plug optional& |
